2 Responses to STORMIDISTORNI …

1. vivalux ha detto:

   30 ottobre 2011 alle 13:25

   CHE COS’E’ LA BELLEZZA?

   /*
   * Boids — A Flocking Simulation
   */

   import controlP5.*;
   ControlP5 controlP5;

   int boidVisibility = 250;
   int numBoids = 300;
   int visibleBoids = 80;
   int maxSpeed = 23;
   boolean debug = false;
   int numFood = 8;

   float meshDiv = 1;
   float meshMult = .3;
   int meshShade = 255;

   boolean meshDraw = false;
   boolean vectorDraw = true;
   boolean mouseFollow = false;
   boolean mouseScary = false;
   boolean smooth = true;
   boolean foodPresent = true;

   int cmfFactor = 8;
   int avoidFactor = 12;
   int allignFactor = 7;

   boid[] myBoids;
   food[] myFood;
   PFont fontA;

   void setup()
   {
   size(900,500);
   frameRate(45);
   smooth();
   ellipseMode(CENTER);

   fontA = loadFont(“CourierNew36.vlw”);
   textFont(fontA, 18);

   controlP5 = new ControlP5(this);
   //controlP5.setColorLabel(50);
   controlP5.addToggle(“toggleVectorDraw”,true, 15,15,20,20).setLabel(“Draw Vectors “);
   controlP5.addToggle(“toggleMeshDraw”,false, 15,50,20,20).setLabel(“Draw Mesh “);
   controlP5.addToggle(“toggleSmooth”,true,15,85,20,20).setLabel(“Smooth Graphics “);
   controlP5.addToggle(“toggleMouseFollow”,false,15,120,20,20).setLabel(“Follow Mouse “);
   controlP5.addToggle(“toggleMouseScary”,false,15,155,20,20).setLabel(“Scary Mouse “);
   controlP5.addToggle(“toggleFoodPresent”,true,15,190,20,20).setLabel(“Food Present “);
   controlP5.addBang(“scatterBoids”,15,225,20,20).setLabel(“Scatter Boids “);
   controlP5.addSlider(“setCmfFactor”,0,20,cmfFactor,15,height-220,20,200).setLabel(“Attraction”);
   controlP5.addSlider(“setAvoidFactor”,0,20,avoidFactor,65,height-220,20,200).setLabel(“Avoidance”);
   controlP5.addSlider(“setAllignFactor”, 0,20,allignFactor,115,height-220,20,200).setLabel(“Alignment”);
   controlP5.addSlider(“setBoidVisibility”,90,800,boidVisibility,165,height-220,20,200).setLabel(“Visibility”);
   controlP5.addSlider(“setFrameRate”, 1,100,45,215,height-220,20,200).setLabel(“Framerate”);
   controlP5.addSlider(“setVisibleBoids”, 1,300,visibleBoids,265,height-220,20,200).setLabel(“Boids”);

   myBoids = new boid[numBoids];
   myFood = new food[numFood];
   for(int i = 0; i < numBoids; i++) {
   myBoids[i] = new boid(random(width),random(height),random(-1,1),random(-1,1));
   }
   for(int i = 0; i < numFood; i++) {
   myFood[i] = new food();
   }

   background(0);
   }

   void setFrameRate(int rate) {
   frameRate(rate);
   }

   void setVisibleBoids(int boids) {
   visibleBoids = boids;
   }

   void setBoidVisibility(int visibility) {
   boidVisibility = visibility;
   }

   void setAllignFactor(int factor) {
   allignFactor = factor;
   }

   void setAvoidFactor(int factor) {
   avoidFactor = factor;
   }

   void setCmfFactor(int factor) {
   cmfFactor = factor;
   }

   void toggleVectorDraw() {
   vectorDraw = !vectorDraw;
   }

   void toggleMeshDraw() {
   meshDraw = !meshDraw;
   }

   void toggleMouseFollow() {
   mouseFollow = !mouseFollow;
   }

   void toggleFoodPresent() {
   foodPresent = !foodPresent;
   }

   void toggleMouseScary() {
   mouseScary = !mouseScary;
   }

   void toggleSmooth() {
   if (smooth == true) {
   smooth = false;
   noSmooth();
   } else {
   smooth = true;
   smooth();
   }
   }

   float scale(int factor) {
   float scaled = (float)(factor) / 10;
   return scaled;
   }

   void scatterBoids() {
   for(int i = 0; i < visibleBoids; i++)
   {
   myBoids[i].xPos = random(width);
   myBoids[i].yPos = random(height);
   myBoids[i].velocity = new vector(random(-1,1),random(-1,1));
   }
   }

   PImage img;

   void draw()
   {
   // background(255);
   background(0);
   /*img=get();
   img.resize(round(width*0.5),round(height*0.5));
   img.resize(width-1,height-1);
   image(img,0,0);
   */
   //fill(0,50); rect(0,0,width,height);
   if (meshDraw)
   for(int i = 0; i < visibleBoids; i++)
   myBoids[i].mesh();

   for(int i = 0; i < visibleBoids; i++) {
   myBoids[i].drawit();
   }

   if (foodPresent)
   for(int i = 0; i < numFood; i++) {
   myFood[i].drawit();
   }

   vector v1, v2, v3, v4, v5;
   for(int i = 0; i < visibleBoids; i++)
   {

   for(int j = 0; j 125) return new vector(0,0);
   vector followVector = new vector(mouseX-myBoids[boidNum].xPos,mouseY-myBoids[boidNum].yPos);
   followVector.mult(-1);
   if (dist < 100) {
   followVector.mult(1.5);
   } else if (dist < 50) {
   followVector.mult(2);
   } else if (dist < 25) {
   followVector.mult(2);
   }
   return followVector;
   }

   vector centerMass(int boidNum)
   {
   vector massVector = new vector(0,0);
   int count = 0;
   for(int i = 0; i < visibleBoids; i++)
   {
   if (i != boidNum)
   if (myBoids[boidNum].close(boidVisibility*1.5,myBoids[i]))
   {
   massVector.add(myBoids[i].xPos,myBoids[i].yPos);
   count++;
   }
   }

   massVector.div(count);
   massVector.add(-myBoids[boidNum].xPos,-myBoids[boidNum].yPos);
   massVector.div(100);

   return massVector;
   }

   vector avoidOthers(int boidNum)
   {
   vector avoidVector = new vector(0,0);

   for(int i = 0; i < visibleBoids; i++)
   {
   if (i != boidNum)
   if (myBoids[boidNum].close(45,myBoids[i])) {
   vector current_avoid = new vector(myBoids[boidNum].xPos-myBoids[i].xPos,myBoids[boidNum].yPos-myBoids[i].yPos);
   float avoid_multiplier = 25 / current_avoid.magnitude();
   current_avoid.bindVector(avoid_multiplier);
   avoidVector.add(current_avoid);
   }
   }

   return avoidVector;
   }

   vector matchVelocity(int boidNum)
   {
   vector velocityVector = new vector(0,0);
   int count = 0;

   for(int i = 0; i < visibleBoids; i++)
   {
   if (i != boidNum)
   if (myBoids[boidNum].close(boidVisibility * .5,myBoids[i]))
   {
   velocityVector.add(myBoids[i].velocity);
   count++;
   }
   }

   velocityVector.div(count);
   velocityVector.sub(myBoids[boidNum].velocity);
   velocityVector.div(8);

   return velocityVector;
   }

   vector hunt_foodstuff(int boidNum) {
   vector velocityVector = new vector(0,0);
   for (int i = 0; i < numFood; i++) {
   if (myFood[i].close(myBoids[boidNum],150)) {
   velocityVector.add(myFood[i].position.x – myBoids[boidNum].xPos, myFood[i].position.y – myBoids[boidNum].yPos);
   }
   }
   return velocityVector;
   }

   class food {
   vector position;
   int amount_left;
   int diameter = 30;

   food() {
   spawn();
   }

   void spawn() {
   position = new vector(random(width),random(height));
   amount_left = diameter;
   }

   boolean close(boid diner, int distance) {
   float dist = sqrt(sq(position.x – diner.xPos) + sq(position.y – diner.yPos));
   return (dist < distance);
   }

   void eaten(boid diner) {
   if (close(diner, diameter)) {
   amount_left–;
   }
   if (amount_left < 0) {
   spawn();
   }
   }

   void drawit() {
   stroke(color(150,30,150));
   fill(color(225,30,225,150));
   ellipse(position.x, position.y, amount_left, amount_left);
   }

   }

   class boid
   {
   float xPos;
   float yPos;
   vector velocity;
   color race;

   boid(float _xPos, float _yPos, float _xV, float _yV)
   {
   this.xPos = _xPos;
   this.yPos = _yPos;
   velocity = new vector(_xV,_yV);
   race = color(random(255),random(255),random(255));
   }

   void move()
   {
   this.xPos += velocity.x;
   this.yPos += velocity.y;
   }

   boolean close(float friendly, boid other)
   {
   float dist = sqrt(sq(this.xPos – other.xPos) + sq(this.yPos – other.yPos));
   if (dist (width+bounds))
   this.xPos = -bounds;
   if (this.yPos > (height+bounds))
   this.yPos = -bounds;
   if (this.xPos < -bounds)
   this.xPos = width+bounds;
   if (this.yPos maxSpeed)
   {
   this.velocity.bindVector(maxSpeed);
   }
   }

   void mesh()
   {

   int alpha = (visibleBoids < 80) ? 40 : 255;
   stroke(color(meshShade,meshShade,meshShade,alpha));
   for(int i = 0; i < visibleBoids/meshDiv; i++)
   {
   if (this.close(boidVisibility,myBoids[i]))
   line(this.xPos,this.yPos,myBoids[i].xPos,myBoids[i].yPos);
   }
   }

   void drawit()
   {
   vector unit = new vector(this.velocity);
   unit.bindVector(20);
   stroke(220);
   if (vectorDraw == true) {
   line(this.xPos,this.yPos,this.xPos+unit.x/1.6,this.yPos+unit.y/1.6);
   }
   stroke(100);
   fill(this.race);
   float radius = 13.0 – 5.0 * ((float)visibleBoids/300);
   ellipse(this.xPos,this.yPos,radius,radius);

   }
   }

   class vector
   {
   float x;
   float y;

   vector()
   {
   x = 0;
   y = 0;
   }

   vector(vector other)
   {
   this.x = other.x;
   this.y = other.y;
   }

   vector(float _x, float _y)
   {
   this.x = _x;
   this.y = _y;
   }

   void add(vector other)
   {
   this.x += other.x;
   this.y += other.y;
   }

   void add(float _x, float _y)
   {
   this.x += _x;
   this.y += _y;
   }

   void sub(vector other)
   {
   this.x -= other.x;
   this.y -= other.y;
   }

   void div(float divisor)
   {
   if (divisor != 0)
   {
   this.x /= divisor;
   this.y /= divisor;
   }
   }

   void mult(float term)
   {
   this.x *= term;
   this.y *= term;
   }

   float magnitude()
   {
   float dot = this.x * this.x + this.y * this.y;
   return sqrt(dot);
   }

   void bindVector(float scalar)
   {
   this.div(this.magnitude());
   this.mult(scalar);
   }

   }

   Rispondi
2. isabella guarini ha detto:

   31 ottobre 2011 alle 09:34

   Gli stormi volavano anche sopra la Piazza del Municipio di Napoli, prima che fosse devastata dall’eterno cantiere della metropolitana. Verso il tramonto,avresti potuto vedere gli storni, riuniti in stormi, disegnare sulla lavagna di cielo anelli di moebius in movimeto: una bella lezione di geometria!:

   Rispondi
